Autodesk Revit Project (5)
FULL SPECS & FEATURES
Basic Features
Bedrooms : 5 Baths : 6 Stories: 2 Garages: 1
Dimension
Depth : 97' Height : 24' 5" Width : 118' 0"
Area
Total : 11,446 sq/ft Bonus: 430 sq/ft height 8'
First Floor: 11,446 sq/ft height 9' Garage: 633 sq/ft
Storage: 35 sq/ft
Bonus Ceiling : 8' Main Ceiling : 9'
Roof
Primary Pitch : 9:12 Roof Framing : stick
Roof Load : 40 Roof Type : shingles
Secondary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : siding, siding Framing : 2"x4"
Bedroom Features
Main Floor Bedrooms Main Floor Master Bedroom
Split Bedrooms Walk In Closet
Kitchen Features
Butler's Pantry Eating Bar Kitchen Island Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room Main Floor Laundry
Mud Room Play Flex Room
Storage Area Unfinished Future Space
Garage Features
Front Entry Garage Oversized Garage
Lot Characteristics
Suited For Corner Lot Suited For Sloping Lot Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Outdoor Kitchen Grill
Rooms
Front & Rear Porches: 354 sq/ft
WHAT'S INCLUDED IN THIS PLAN SET
Purchasing a CAD set gives you an unlimited build license.
Cover Sheet – May include index, front view of home, definitions, etc.
Exterior Views – Four exterior views of the residence with other miscellaneous details.
Roof Plan – Birds eye view showing all ridges, valleys and other necessary information.
